TP-Link RE305 AC1200 Dual Band Wifi Range Extender/AP, 1x10/100 RJ45, power schedule

Bezdrôtový Extender RE305

*Oživí mŕtve zóny vo Wi-Fi sieti vďaka silnému rozšíreniu s kombinovanou rýchlosťou prenosu dát až 1,2Gbit/s

*Pracuje vobou pásmach 2,4GHz (300Mbit/s) aj 5GHz (867Mbit/s) a zaistí stabilnejšie používanie bezdrôtovej siete

*Inteligentná kontrolka signálu pomáha vďaka indikácii sily signálu nájsť pre extender najlepšie umiestnenie, aby pokrytie Wi-Fi signálom bolo optimálne

*Pracuje s akýmkoľvek Wi-Fi routerom alebo bezdrôtovým access pointom

HARDWARE FEATURES

*Plug Type

EÚ, UK, US

*Standards and Protocols

IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b

*Interface

1 * 10/100M Ethernet Port (RJ45)

*Buttons

WPS Button, Reset Button

*Power Consumption

7.3W(max power consumption)

*Antenna

2* external

*Dimensions ( W x D x H )

80*78*77mm

WIRELESS FEATURES

*Frequency

2.4GHz & 5GHz(11ac)

*Signal Rate

5GHz:Up to 867Mbps

2.4GHz:Up to 300Mpbs

*Reception Sensitivity

*5GHz:

11a 6Mbps:-91dBm@10% PER

11a 54Mbps: -74dBm@10% PER

11ac HT20 mcs8: -68dBm@10% PER

11ac HT40 mcs9: -63dBm@10% PER

11ac HT80 mcs9: -59dBm@10% PER

*2.4GHz

11g 54M: -79dBm@10% PER

11n HT20 mcs7: -77dBm@10% PER

11n HT40 mcs7: -74dBm@10% PER

*Wireless Modes

Range Extender/Access Point

Wireless Statistic

Concurrent Mode boost both 2.4G/5G Wi-Fi band

*Wireless Functions

Wireless Statistic

Concurrent Mode boost both 2.4G/5G Wi-Fi band

Access Control

LED Control

Domain Login Function

*Wireless Security

64/128-bit WEP

WPA-PSK / WPA2-PSK

*Transmission Power

<17dBm(2.4GHz)

<17dBm(5GHz)

*OTHERS

*Certification

CE, FCC, RoHS

*Package Contents

AC1200 Wi-Fi Range Extender RE305

Quick Installation Guide

*Box Dimensions (WXDXH)

156.5*101.5*95mm

*System Requirements

Microsoft® Windows® 98SE, NT, 2000, XP, Vista alebo Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® alebo Linux.

*Environment

Operating Temperature: 0°C~40°C

Storage Temperature: -40°C~70°C

Operating Humidity: 10% ~ 90% non-condensing

Storage Humidity: 5% ~ 90% non-condensing
